Micromod MOD: 1731N ICN Mini-Link Users Guide User Manual
Page 17

IB-23C003
INSTALLATION
Table 2-6. Mini Link External Serial Port Baud Rates
* Not recommended for use with currently available software.
BAUD
Jumper IN
W12
W11
W10
W9
W8
76800*
Y
N
N
N
N
38400*
N
Y
N
N
N
19200
N
N
Y
N
N
9600
N
N
N
Y
N
Clear-To-Send (CTS) for Serial Ports 1 and 2
Both the PC/AT and the External Serial Ports are outfitted with a CTS connection. In most
cases, the CTS signal will not be needed. In the event that your configuration requires a
CTS signal, install jumpers W1 and W2 as follows:
W1
Enables Clear To Send on External Serial Port 2
W2
Enables Clear To Send on PC/AT Serial Port 1
RS-232 Test Signal Jumper
Jumper W22 provides access to the 5V power plane of the Mini Link. If Jumper W22 is
connected, the 5V signal will appear on pin 9 of the RS-232 connector. This jumper will
normally be used for test purposes only.
2-5
