220-000-350 © 2004 Max Machinery, Inc.
Dimensional Drawing
1000 PSI RATED VERSIONS
*Model 220-3XX 3.35 (85)
221-3XX 4.12 (105)
222-3XX 5.34 (136)
See
Below*
4.75
(121)
2.75
(70)
3.5
(89)
4.0
(102)
4.0
(102)
1/2” NPT
7/8-14 SAE (optional)
1.75
(45)
3.125
(79)
3/16 diameter probe
hole with 1/8 NPTfitting
1/8 diameter probe
hole with 1/16 NPTfitting
Thermocouple and RTD
Discontinued
