220-000-350 © 2004 Max Machinery, Inc. Page 11
221 Series Gear Flowmeters — Pressure Drop
S ERIES 221 P RESSURE D ROP :
Delta P vs Flow Rate (at various viscosities)
(This Flowmeter is generally used for 100 CPS or greater viscosities.)
Typical Flowmeter Specifications
Displacement: 23.5 cc/rev
Pulses/CC with 284-XXX Transmitter: 4.26
Maximum Pressure: 1500 PSI standard
3000 PSI High Pressure
Discontinued
