Max Machinery 220, 221 and 222 FLOW METERS - Manual (Page 13)

220-000-350 © 2004 Max Machinery, Inc. Page 13
222 Series Gear Flowmeters — Pressure Drop
S ERIES 222 P RESSURE D ROP :
Delta P vs Flow Rate (at various viscosities)
(This Flowmeter is generally used for 100 CPS or greater viscosities.)
Typical Flowmeter Specifications
Displacement: 47.4 cc/rev
Pulses/CC with 284-XXX Transmitter: 2.11
Maximum Pressure: 1500 PSI standard
3000 PSI High Pressure
Discontinued
