222 Series Gear Flowmeters — Linearity
S
ERIES
222 L
INEARITY
:
Typical Linearity (at various viscosities)
(This Flowmeter is generally used for 100 CPS or greater viscosities.)
Maximum Error:
-10 cc/min. or 0.75%
Typical Flowmeter Specifications
Displacement:
47.4 cc/rev
Pulses/CC with 284-XXX Transmitter:
2.11
Maximum Pressure:
1500 PSI standard
3000 PSI High Pressure
