120-200-350 © 1993 (Rev 5/97) Max Machinery, Inc.

Page 27

RS-485 SERIAL COMMANDS

Command

Response

Description

L36 aa

A

Load Zero Rate Time
where

aa = Zero Time (01 - 15)

Q36

A36 aa

Query Zero Rate Time
where

aa = Zero Time

L37 aaa

A

Load Rate Display Header
where

aaa = Rate Display Header

(Space or Uppercase letters)

Q37

A37 aaa

Query Rate Display Header
where

aaa = Rate Display Header

L41 a b

A

Load Key Lock (Keys 2, 4, 5)
where

a = Key Number (2, 4, 5)

b = 0 - Unlocked

= 1 - Locked

Q41

A41 a b ...

Query Key Lock (Keys 2, 4, 5)
where

a = Key Number (2, 4, 5)

b = 0 - Unlocked

= 1 - Locked

L45 a

A

Load Count Speed
where

a = 0 - Low - 40 Hz Max.

= 1 - Med. - 400 Hz Max.
= 2 - High - 7500 Hz Max.

Q45

A45 a

Query Count Speed
where

a = 0 - Low - 40 Hz Max.

= 1 - Med. - 400 Hz Max.
= 2 - High - 7500 Hz Max.
