RS-485 SERIAL COMMANDS
Command Response Description
L32 a b A Load Rate meter Control Input
where
a = Control Input (1-5)
b = 0 - No function
= 1 - Unlatch Alarms
Q32 A32 a b ... Query All Rate meter Control Inputs
where
a = Control Input (1-5)
b = 0 - No Function
= 1 - Unlatch Alarms
L33 a bbbb cccc A Load Rate meter Output Function
where
a = 0 - Timed Outputs
bbbb = Low Rate Output Time
cccc = High Rate Output Time
- or -
L33 a
a = 1 - Outputs Follow
Q33 A33 a bbbb cccc Query Rate meter Output Function
where
a = 0 - Timed Outputs
bbbb = Low Rate Output Time
cccc = High Rate Output Time
- or -
Q33
A33 a where a = 1 - Outputs Follow
L34 a A Load Rate meter Reset Key Function
where
a = Reset Key Function
= 0 - No Function
= 1 - Unlatch Outputs
Q34 A34 a Query Rate meter Reset Key Function
where
a = Reset Key Function
= 0 - No Function
= 1 - Unlatch Outputs
L35 a A Load Rate meter D.P. Location
where
a = 0 - No Dec. Pt.
= 1 - XXXXX.X
= 2 - XXXX.XX
= 3 - XXX.XXX
= 4 - XX.XXXX
= 5 - X.XXXXX
Q35 A35 a Query Rate meter D.P. Location
where
a = 0 - No Dec. Pt.
= 1 - XXXXX.X
= 2 - XXXX.XX
= 3 - XXX.XXX
= 4 - XX.XXXX
= 5 - X.XXXXX
