Figure 2b, Figure 2c, Figure 2d – Mallory Ignition Mallory COMP PUMP ELECTRIC FUEL PUMP SERIES 110_140 User Manual
Page 3: Figure 3
3
FIGURE 2B
FUEL PUMP KIT PART NO. 4142 WITH FUEL
PRESSURE REGULATOR PART NO. 4309
CARB.
FUEL
FILTER
FUEL
PUMP
FUEL
FILTER
COMP
®
FILTER
PART NO.
3140
FUEL
TANK
REGULATOR
FUEL RETURN
FIGURE 2C
FUEL PUMP KIT PART NO. 4140 OR 4141 WITH FUEL PRESSURE
REGULATOR PART NO. 4207 OR 4209
REGULATOR
CARB.
FUEL
FILTER
FUEL
PUMP
FUEL
TANK
FUEL
FILTER
COMP
®
FILTER
PART NO.
3140
NITROUS SYSTEM
GAS SOLENOID
FUEL
FILTER
FUEL
PUMP
REGULATOR
FUEL RETURN
FIGURE 2D
FUEL SYSTEM FOR NITROUS OXIDE FUEL PUMP KIT
PART NO. 4142 WITH FUEL PRESSURE REGULATOR
PART NO 4309
FIGURE 3
TO ACCESSORIES
IGNITION SWITCH
OIL PRESSURE
SWITCH
FROM
VEHICLE
BATTERY
TO COIL (+)
NORMALLY
OPEN
NORMALLY
CLOSED
COMMON
FUSE (7.5 AMP)
FUEL
PUMP
GROUND
GROUND
VEHICLE
BATTERY
STARTER
12 VOLT OUTPUT TERMINAL
ON STARTER THAT HAS 12
VOLT ONLY WHILE STARTER
IS CRANKING
RED
BLACK
