Custom fit application – plug-in harness diagrams – Mallory Ignition ACCEL 275_300 digital ignition 49275_49300 User Manual
Page 5
5
Use this harness to connect
your ACCEL 300+ to a
1984-95 GM HEI remote coil
(Small distributor cap)
CUSTOM FIT PART NUMBER 49321
CUSTOM FIT PART NUMBER 49322 & 49323
Use this wiring harness to connect your
ACCEL 300+ to a 1973-91 GM HEI In-Cap
Distributor with the module in place
CUSTOM FIT APPLICATION – PLUG-IN HARNESS DIAGRAMS
