Gelcoat gun front – Magnum Venus Plastech TALON Gun Internal Mix User Manual
Page 23
Talon Internal Mix Gun Manual
Rev. 10/2013
Page | 23
Gelcoat Gun Front:
Note: the TLN-IG-200X-XX Talon gun assembly uses the VPA-1000-VFIT Air Assist
assembly
– FIT and VFIT-XXXX Spray Tips. The TLN-IG-100X-XX Talon gun
assembly uses the VPA-1000 Air Assist assembly and ATG-XXX Spray Tips.
Gun Head
Mix Housing Seal
Catalyst Injector
Distribution Ring
Mix Chamber
Cap Screw (2 pls)
Turbulent Mixer
VPA-1000 Air Assist Assembly or
VPA-1000-VFIT Air Assist
