RT-3000 Remote Trigger Manual
Rev. 12/2012 Page | 26
Start-Up Checklist for FIT Chop
ACTIVITIES MUST BE DONE IN THE SEQUENCE SHOWN, AND MUST BE TICKED
OFF AS COMPLETED. USE THIS CHECKLIST IN CONJUNCTION WITH THE
OPERATING MANUAL FOR THE ULTRAMAX UNIT. THIS SEQUENCE FOLLOWS
ON FROM CHECKLIST 02 – START UP CHECKLIST
ACTIVITY
NO.
ACTIVITY
TICK WHEN
COMPLETED
Priority
Put on Respirator as specified for spray painting, Protective
Clothing, Eye Protection, and PVC Gloves
1 Apply Red grease to the Mix Housing Threads.
2 Insert the Turbulent Mixer into the Stainless Steel Mix Housing Chamber.
It must have a tight fit. (2,25 kg or less per minute, use Critical Turbulent
Mixer, for more than 2,25kg per minute, use Standard Turbulent Mixer.)
3 Install the FIT spray tip and nozzle cap onto the Mix Chamber (do not
overtighten)
4 Spray a test pattern onto a wide paper test strip. Observe the pattern.
♦
Too wide with poorly defined “horns” – turn down the pump pressure
♦ Too narrow but with well defined “horns” – turn up the pump
pressure.
♦ Good width with well defined “horns” – optimised for low emission
spraying.
Use pump pressure to adjust to a pattern that has uniformity in gaps
between streams, and no streaking
5 Flush the Mix Chamber with solvent
6 Turn Resin Pump regulator to Zero.
The Unit is now set up for Spray Trials.
ABNORMAL CONDITIONS OBSERVED AND CORRECTED
Abnormal Condition
a a a a when corrected
OPERATORS NAME _______________________________________ DATE: ___________
SIGN OFF WHEN SET UP CHECKS ARE COMPLETED: __________________________
Note: Before spraying a part always check that the catalyst recirculation valve is closed and
catalyst pump is primed.
