Magnum Venus Plastech RT-3000 PRO GUN CHOP TRIGGER User Manual
Page 19
RT-3000 Remote Trigger Manual
Rev. 12/2012
Page | 19
Plug Assembly:
14. Install the inner guard into the two haves of the plug shell.
.
15. Install the four screws holding the outer shell of the plug together.
Optional Valve Package (SV01):
For systems using the SV01 Safety Override valve the gun “on” signal should tee into
the pump “on” signal, turning on both the gun and pump.
ITEM
PART NO.
QTY.
DESCRIPTION
1
8407-4-1
1
3-WAY VALVE
2
8407-3-1
1
SHUTTLE VALVE
3
8407-1-1
1
3-WAY VALVE
