AR – 1202
RTC
ARCHITECTURAL DIMMER
Revision
1.93
OWNERS
MANUAL 06/03/2008
www.lightronics.com
Lightronics Inc.
509 Central Drive Virginia Beach, VA 23454
Tel 757 486 3588
AR-1202 UNIT SPECIFICATIONS
CHANNELS/CAPACITY:
12 Channels @ 2400 Watts each channel
POWER REQUIREMENTS:
120/208VAC three phase,80 Amps each line
OR
120/240VAC
single
phase,
120
Amps
each
line
POWER DEVICES:
Dual 65 Amp SCRs
POWER CONNECTOR:
Terminal strip
CHANNEL OUTPUT:
Terminal Strip
CIRCUIT BREAKERS:
20 Amp fast acting
MINIMUM
LOAD:
15
Watts
CURVE:
Modified
square
law
FILTER RISE TIME:
600 usec. minimum
OUTPUT FUNCTION:
DIMMER or RELAY selectable
CONTROL INPUT:
DMX-512 U.S.I.T.T. standard
FRONT PANEL:
8 char. x 2 line LCD display
REMOTE NETWORK:
RS-485, 62.5 Kbaud, bidirectional 9 bit network
LOCAL PRESETS:
100 scenes standard. Expandable to 255 scenes
CLOSURE INPUT:
8 inputs for single, dual button, or combine stations
REMOTE STATIONS:
Total of 32 remote stations with unique system addresses
SLAVE UNITS:
Up to 31 additional units may be added
SIZE :
21 1/8"H x 20 1/4"W x 6 1/4"D
WEIGHT:
61 lbs (70 lbs shipping weight)
