AR – 1202 RTC ARCHITECTURAL DIMMER
Revision 1.93 OWNERS MANUAL 06/03/2008
www.lightronics.com
Lightronics Inc. 509 Central Drive Virginia Beach, VA 23454 Tel 757 486 3588
CHANNEL NON-DIM (RELAY) MODE
To set a channel to Non-Dim: Push
MENU (NEXT)
until the Dimmer Setup menu appears on the display.
Push
ENTER . Then push MENU (NEXT) . The
display will show the menu:
Use the and buttons to select a channel. Then
use the and buttons to switch between DIMMER
and NON-DIM. Push
ENTER when finished.
DMX I/O SETUP
DMX I/O Setup consists of two functions. Dimmer
channel assignment and Remote lockout
DIMMER CHANNEL ASSIGNMENT
Dimmer channel aggignment is used to assign
individual AR-1202 channels (circuits) to a DMX
control channel. Each dimmer channel (1 - 12) is
fully patchable to any of 512 DMX control channels.
At the AR-1202 front panel - push MENU (NEXT)
until the DMX I/O Setup menu appears on the
display.
Push ENTER. The display shows AR-1202 dimmer
channels on the top line. The currently assigned DMX
channel is shown on the lower line prefixed by
“DMX” .
Use the and buttons to select a dimmer
channel.
Then use the and buttons to assign it to a DMX
channel. Push
ENTER after each channel assignment.
Push CLEAR to exit from the menu. It will not clear
your settings.
CONSOLE LOCKOUT: You can set any dimmer
channel output to ignore DMX signal inputs from a
DMX console by assigning it to DMX channel 0.
This feature can be used with house lights or other
special lighting. The channel will still respond to wall
remotes but the DMX console will be ignored.
REMOTE LOCKOUT
The Remote Lockout function prevents the AR-1202
from responding to the smart remote wall stations
when a DMX signal from a console is present. Simple
remote stations will still function.
At the AR-1202 front panel - push
MENU (NEXT)
until the DMX I/O Setup menu appears on the
display.
Push
ENTER. Then push MENU (NEXT) . The display
will show the lockout menu.
Use the and buttons to select ON or OFF. Push
ENTER when the desired state is shown.
CREATING AND EDITING SCENES
At the AR-1202 front panel - push MENU (NEXT)
until the Scene Setup menu appears on the display.
Push ENTER . The display shows the current scene
number.
Use the and buttons to select the scene you
want to set up and push
ENTER . Scene 00 controls
blackout fade time. Scene 01 is the first actual scene.
DMR 01
DMX 001
SCENE
SETUP
SCENE
000
01 CRV
DIMMER
DMX I/O
SETUP
DIMMER
SETUP
DMX REM
LKOUT N
DMX I/O
SETUP
