ADTRAN NetVanta 344 - Manual (Page 2)

ADTRAN is an ISO 9001, ISO 14001,
and a TL 9000 certified supplier.
Physical Interface
■ DSL: ADSL/ADSL2/ADSL2+ Interface
ADSL ITU G.992.1 (Annex A)
ADSL ITU G.992.2 (Annex A) G.Lite
Extended Reach ADSL (RADSL)
ADSL2 ITU G.992.3 (Annex A)
ADSL2+ ITU G.992.5 (Annex A)
■ Ethernet: Four-port, Auto-sensing Ethernet Switch
10/100Base-T Full Duplex (RJ-45)
Diagnostics LEDs
■ Power
■ Ethernet
■ DSL
■ Internet
Memory
■ RAM: 32 MB
■ FLASH: 16 MB
Protocols
■ eBGP/iBGP ■ PPP over ATM (RFC 2364)
■ OSPF ■ PPPoE over ATM (RFC 2516)
■ RIP (v1 and v2) ■ Classical IP over ATM (RFC 2225)
■ Demand Routing ■ AAL5
■ GRE ■ PAP and CHAP
■ IGMP v2
Quality of Service
■
DSL: Low Latency, Weighted Fair Queuing (WFQ),
and Class-based WFQ
■ Ethernet: Weighted Round Robin (WRR) and
Strict Priority Queuing
■ DiffServ Packet Marking and Recognition
■ Frame Relay Fragmentation
Switching
■ VLAN Support (802.1Q)
■ Spanning Tree (802.1D)
■ Rapid Spanning Tree (802.1w)
■ 802.1p and DiffServ QoS
Administration
■ Familiar Command Line Interface (CLI)
■ Web-based GUI
■ n-Command ® support
■ SNMP v3
■ SYSLOG Logging
■ Email Alerts (SMTP)
■ Policy Statistics
DHCP
■ Client, Server, and Relay
NetVanta
®
344
Business-class ADSL/ADSL2/ADSL2+ Router with Four-port Switch
Security
Firewall
■ Stateful Inspection Firewall
■ Denial of Service (DoS) Protection
■ Access Control Lists
■ Application Level Gateways (ALGs)
Network Address Translation
■ Basic NAT (1:1), NAPT (Many:1), and Port Translation
■ NAT compatible SIP ALG
Secure Management
■ Multilevel access control ■ TACACS+
■ RADIUS AAA ■ SSH CLI and SSL GUI
Optional Virtual Private Network (VPN)
■ IPSec Tunnel Mode: 5 Tunnels
■ Encryption: DES, 3DES, and AES
■
Diffie Hellman Group Support: Group 1: MODP 768
and Group 2: MODP 1024
■ Hash Algorithms: MD5-HMAC and SHA1-HMAC
■ Authentication Mechanisms: XAUTH, Digital
certificates, Preshared keys, and Secure ID
■ Key Management: IKE (ISAKMP/Oakley)
■ IKE Modes: Main and Aggressive
■
Dead Peer Detection
■ NAT Traversal V2
Environment
■ Operating Temperature: 0° to 50 °C (32° to 122 °F)
■ Storage Temperature: -20° to 70 °C (-4° to 158 °F)
■ Relative Humidity: Up to 95%, non-condensing
Physical
■ Chassis: Self-standing, plastic enclosure
■ Dimensions: 1.625“ H, 7.5“ W, 5.25“ D
■ Weight: 1 lb.
■ Power: 12 VDC, 800 mA, 6 W
(AC to DC Power Adapter Included)
Agency Approvals
■ FCC Part 68 ■ Industry Canada CS03
■ CE Mark, UL and Canadian UL (CUL), IEC/EN, CSA
Ordering Information
Equipment Part #
Systems
NetVanta 344 Chassis 1200426E1
Systems with VPN
NetVanta 344 with VPN 4200426E2
VPN Software Upgrade
NetVanta 344 VPN Software Upgrade 1950426L2
