Laurel Electronics LAUREATE SERIES Serial Comunications User Manual
Page 32
NON-VOLATILE MEMORY ADDRESSES (2 bytes/address)
Sign + Magnitude
XXXX XXXX XXXX XXXX XXXX XXXX
S=Sign
S
Magnitude
Sign = 1 for negative
Sign+DP+Magnitude XXXX XXXX XXXX XXXX XXXX XXXX
DP = 1 = DDDDDD.
S DP
Magnitude
DP = 6 = D.DDDDD
* These values are used only during Reset and are not available in RAM.
Address
Most Significant Byte
Least Significant Byte
Stored As
1A *
Analog High 3
Analog High 2
2’s Complement
19 *
Analog High 1
Analog Low 3
2’s Complement
18 *
Analog Low 2
Analog Low 1
2’s Complement
17
Deviation2 3
Deviation2 2
Pos Magnitude
16
Deviation2 1
Deviation1 3
Pos Magnitude
15
Deviation1 2
Deviation1 1
Pos Magnitude
14
Offset2 3
Offset2 2
2’s Complement
13
Offset2 1
Scale2 3
2’s CPL / S+M
12
Scale2 2
Scale2 1
Sign + Magnitude
11
Offset1 3
Offset1 2
2’s Complement
10
Offset1 1
Scale1 3
2’s CPL / S+M
0F
Scale1 2
Scale1 1
Sign + Magnitude
0E
Setpoint2 3
Setpoint2 2
2’s Complement
0D
Setpoint2 1
Setpoint1 3
2’s Complement
0C
Setpoint1 2
Setpoint1 1
2’s Complement
0B *
High Reading2 3
High Reading2 2
2’s Complement
0A *
High Reading2 1
High Input2 3
2’s CPL / S+DP+M
09 *
High Input2 2
High Input2 1
Sign+DP+Magnitude
08 *
Low Reading2 3
Low Reading2 2
2’s Complement
07 *
Low Reading2 1
Low Input2 3
2’s CPL / S+DP+M
06 *
Low Input2 2
Low Input2 1
Sign+DP+Magnitude
05 *
High Reading1 3
High Reading1 2
2’s Complement
04 *
High Reading1 1
High Input1 3
2’s CPL / S+DP+M
03 *
High Input1 2
High Input1 1
Sign+DP+Magnitude
02 *
Low Reading1 3
Low Reading1 2
2’s Complement
01 *
Low Reading1 1
Low Input1 3
2’s CPL / S+DP+M
00 *
Low Input1 2
Low Input1 1
Sign+DP+Magnitude
-31-
