RAM HEX DATA TABLE
MS Mid LS
A1 A0 9F Analog high value
9E 9D 9C Analog low value
9B 9A 99 Deviation Alarm2
98 97 96 Deviation Alarm1
8F 8E 8D Offset value
8C 8B 8A Scale factor
89 88 87 Setpoint 2
86 85 84 Setpoint 1
NONVOLATILE MEMORY ADDRESSES (2 bytes/address)
See the corresponding itemsin RAM for data significance.
Address Most Significant Byte Least Significant Byte
18 Deviation2 3 Deviation2 2
17 Deviation2 1 Deviation1 3
16 Deviation1 2 Deviation1 1
15 Configuration SC Type (Do not change)
14 Analog Setup System Decimal Point
13 Lockout 2 Lockout 1
12 Serial Cnfg 2 Serial Cnfg 1
11 Options Filter
10 Setup Input Type
0F Alarm Cnfg 2 Alarm Cnfg 1
0E Analog High 3 Analog High 2
0D Analog High 1 Analog Low 3
0C Analog Low 2 Analog Low 1
0B High Reading 3 High Reading 2
0A High Reading 1 High Input 3
09 High Input 2 High Input 1
08 Low Reading 3 Low Reading 2
07 Low Reading 1 Low Input 3
06 Low Input 2 Low Input 1
05 Offset 3 Offset 2
04 Offset 1 Scale Factor 3
03 Scale Factor 2 Scale Factor 1
02 Setpoint2 3 Setpoint2 2
01 Setpoint2 1 Setpoint1 3
00 Setpoint1 2 Setpoint1 1
