Impulse 3405 User Manual
Page 15
Technical
Description
Sealevel Systems VERSA COMM+4/EX Page
12
DB-37 Male
Port #
1
2
3
4
GND
33 14 24 5
TD
35 12 26 3
RTS 17
30
8
21
DTR
34 13 25 4
RD
36 11 27 2
CTS 16
31
7
22
DSR 18
29
9
20
DCD
37 10 28 1
RI 15
32
6
23
Technical Note: Please terminate any control signals that are not going to be
used. The most common way to do this is connect RTS to CTS and RI. Also,
connect DCD to DTR and DSR. Terminating these pins, if not used, will help
insure you get the best performance from your adapter.
