Installation
Sealevel Systems VERSA COMM+4/EX Page
9
Installation
Operating System Installation
For Windows Users
Start by choosing Install Software at the beginning of the CD. Choose
Asynchronous COM: Port Software, SeaCOM.
Other Operating Systems
Refer to the appropriate section of the Serial Utilities Software.
System Installation
The VERSA COMM+4/EX can be installed in any of the PC ISA expansion
slots. The VERSA COMM+4/EX contains several jumper straps for each port
that must be set for proper operation.
1. Turn off PC power. Disconnect the power cord.
2. Remove the PC case cover.
3. Locate an available slot and remove the blank metal slot cover.
4. Gently insert the VERSA COMM+4/EX into the slot. Make sure that the
adapter is seated properly.
5. Replace the screw.
6. Replace the cover.
7. Install the “Spider Cable”.
8. Connect the power cord.
Installation is complete.
