ACB-104.ULTRA User Manual
Introduction
ACB-104.ULTRA
The ACB-104.ULTRA part number 3514 digital I/O interface provides 48 channels
The ACB-104.ULTRA adapter provides the PC/104-Plus computer with a single
channel high-speed multi-protocol serial interface suitable for the most popular
communication protocols. This sync/async card provides an ideal solution for high-
speed applications including LAN/WAN connectivity. Utilizing the Zilog Z16C32
(IUSC™) on chip DMA controller eliminates bus bandwidth constraints that are
placed on typical interface adapters, allowing data rates to reach 10M bps in burst
mode. By utilizing the Z16C32's 32 byte FIFO buffer coupled with 256K of on board
memory, higher data rates are achieved.
Other Sealevel Sync Products
PC/104
ACB-104
(P/N 3512)
- Z85230 RS-232/422/485/530/530a/V.35
PCI
Route 56.PCI
(P/N 5101)
- Z16C32 RS-232/422/485/530/530a/V.35
ACB-MP.PCI
(P/N 5102)
- Z85230 RS-232/422/485/530/530a/V.35
Low Profile PCI
ACB-232.LPCI
(P/N 5103)
- Z85230 RS-232
ACB-Ultra.LPCI (P/N 5104)
- Z16C32 RS-232/422/485/530/530a/V.35
PCMCIA
PC-ACB-MP
(P/N 3612)
- Z85233 RS-232/422/485/530/530a/V.35
ISA
ACB-III
(P/N 4010)
- Z85230 2-Port RS-232
ACB 56
(P/N 4021)
- Z85230 RS-232/V.35
ACB-II/EX (P/N
4061)
-
Z85230 RS-232/422/485/530
ACB 530
(P/N 4111)
- Z85230 2-Port RS-422/485/530
Route 56
(P/N 5011)
- Z16C32 RS-232/422/485/530/V.35
