Specifications – Impulse ACB-104 (3512) User Manual
Page 14
Specifications
Sealevel Systems ACB-104 Page
11
Specifications
Environmental Specifications
Specification Operating
Storage
Temperature
Range
0º to 50º C
(32º to 122º F)
-20º to 70º C
(-4º to 158º F)
Humidity Range
10 to 90% R.H.
Non-Condensing
10 to 90% R.H.
Non-Condensing
Power Consumption
Supply line
+5
Rating
350ma
Mean Time Between Failures (MTBF)
Greater than 150,000 hours. (Calculated)
Physical Dimensions
Board length
3.75 inches
(9.54 cm)
Board Height including Goldfingers
3.5 inches
(8.89 cm)
Board Height excluding Goldfingers
3.2 inches
(8.12 cm)
Please see Appendix G for board layout and dimensions.
