© 2013

www.hysecurity.com

Page 7

Wire

Bracket

Assemble the Arm Linkage as shown in the illustration.

Tighten the fasteners securely using two box end wrenches.

Tip

: Have an assistant, manually raise the M30 Arm so it clears

the Catch Post and provides easier access to the Arm Linkage fasteners.

LED Cable Connections

Arm Linkage

Elbow

Traffic Light

M30 LINK ARMS & INSTALL LIGHT

Replace the Top Clamp and ten fasteners.

Tighten securely to 75 ft

lbs (102 N

m).

2

3

Assemble the Traffic Light:
A. Open the Traffic Lights access panels and feed

the wire through the pipe (remove the threaded

elbow if necessary).
B. Secure the pipe inside the access panel with the
fasteners shown and tighten them securely.
C. Replace the threaded elbow.
D. Connect the traffic and LED arm lights to the

Smart Touch Controller. Wires are color-coded.

Match spade and bullet connectors.

4

D

Upper Pivot Pin

Rubber bushings

Bearing screws (4x)

Torque to 150 ftlb. (203 Nm)

Rear View

1

StrongArm M30 Installation & Assembly - Link Arms and Install Traffic Light

D0432 Rev D

LED Arm Light

cable wire

Restraining

strap

Top clamp

Feed wires

through hole in

chassis & route

through conduit to the Smart Touch Controller.

Reset

Program

Green = Operate

Yellow = Program

Red = Fault

Select

Stop

Next

Close

Previous

Open

Smart Touch Controller

Security

Hy

®

I ON

I ON

O

OFF

Threaded

Elbow

Pipe

Open Traffic Light

access panels

Wire (Tape the ends of the wire to feed

through the pipe and elbow.)

Taped end

Secure pipe

inside access panel

with 1 large rubber washer,

1 silver washer, and 1 nut.

A

B

C

Lock nut and bronze toothed washer

Traffic light chassis

Connect wires

(black to black,

white to white, &

red to red).

Bundle and tie

wrap all the wires

above the display

keypad’s white

box.

NOTE: The wiring

harness for

2 traffic lights is

not shown.

STOP BUTTON

OPEN BUTTON

CLOSE BUTTON

REMOTE OPEN AND

RADIO CONTROL

OPEN/CLOSE

1

OPEN PARTIAL

INTERLOCK OPEN

TIME CLOCK OPEN

FREE EXIT DETECTOR

DISABLE EXIT DETECTOR

DISABLE CLOSE TIMER

INSIDE OBSTRUCTION

VEHICLE DETECTOR
OUTSIDE OBSTRUCTION

VEHICLE DETECTOR

SHADOW/RESET

VEHICLE DETECTOR

EDGE SENSOR

PHOTO EYE POWER

24 VOLTS COMMON
PHOTO EYE POWER

DO NOT USE

PHOTO EYE

OPEN DIRECTION

DO NOT USE

PHOTO EYE

CLOSE DIRECTION

DO NOT USE

CHARGER

AC LOSS

SPARE INPUT

EMERG CLOSE

FIRE DEPT OPEN

2

3

4

5

6

7

8

9

10

11

12

14

15

16

17

18

19

20

21

22

23

24

Smart Touch Controller

LIMIT

DUAL GATE

RADIO OPTIONS

DRIVE

POWER

RS485

MO
TO

RU

SER
1

USER

2

USER

3

VEHICLE DETE

CT

OR

VEHICLE DETE

CT

OR

VEHICLE DETE

CT

OR

ST

OP

/BUZZE

R

FRE
E

EXI

T

INSIDE

OBST

R

OUTSID

E

OBST

R

SHAD

OW

RESE
T

WI

EG

AN

D

HySecurity

COM

NO

MX000585

VERSION

S/N

RS232

DISPLA

Y

VEHICLE DETE

CT

OR

COM

COM

A

B

RPM

COM

OPEN

EDGE

+24V

+24V

STATUS

LED

SI

D

R

D
