Three button station system, See push button connections below, Ped-sw jumper – Controlled Products Systems Group AOMSW300DC User Manual
Page 21: Open close stop, N.c. com, 900r3, 91 1c 0
20
N.C.
COM
THREE BUTTON STATION
SYSTEM
Connect the
from all the push buttons
to
input on the board.
Connect
push button
contact to
input on the board.
Connect
push button
contact to
input on the board.
Connect
push button
Contact to
input on the board and remove
jumper.
COMMON
COMMON
OPEN
N.O.
EXIT
CLOSE
N.O.
3BT
STOP
N.C.
PED-SW
PED-SW
See push button connections below.
OPEN
CLOSE
STOP
A three button station was integrated into the
board to make adjustments easier when
setting limit switches and adjusting ERDs.
