SAFETY Loop
Detector
PHOTO Beam
EXIT
Loop
Detector
Keypad
or
Telephone
Push Button
or
Fire Box
Card Reader
or
Key Switch
See page 17 for connection of
multiple safety device wiring
diagram.
See page 18 for plugin detector
installation. Remove wire jumper
from when
a safety device is
installed.
SAFETY
ACCESSORY CONNECTIONS
B A
= NORMALLY OPEN CONTACT
N/C
= NORMALLY CLOSED CONTACT
C
= COMMON
N/C
N/O
The circuit board output provides up to mAmps of power for accessories. More
than two or three accessories will require a separate power supply.
12VDC Accessories only.
12-VDC 500
