SECTION 4 – OPERATING INSTRUCTIONS
WARNING - To reduce the risk of injury or death:
READ AND FOLLOW ALL INSTRUCTIONS.
Never let children operate or play with gate controls. Keep the remote control away from children.
Always keep people and objects away from gate. NO ONE SHOULD CROSS THE PATH OF THE
MOVING GATE
Test the operator monthly. The gate MUST reverse on contact with a rigid object or stop or reverse
when an object activates the non-contact sensors. After adjusting the force or the limit of travel, retest
the gate operator. Failure to adjust and retest the gate operator properly can increase the risk of
injury or death.
Use the emergency release only when the gate is not moving and power has been shut-off.
KEEP GATES PROPERLY MAINTAINED. Read the owner's manual. Have a qualified service person
make repairs to gate hardware.
The entrance is for vehicles only. Pedestrians must use separate entrance.
SAVE THESE INSTRUCTIONS.
4.1 Power and Reset Switches
Open the power switch cover located on the side of the operator to access the MAIN POWER switch
and the operator RESET switch (Figure 37).
OFF
AC
POWER
RESET
• The RESET switch is used to turn off
the entrapment alarm and to reset
the operator after a hard shutdown
has occurred.
• The AC POWER toggle switch turns
power to the operator ON (toggle up)
or OFF (toggle down).
Figure 32
