Sub-título overlays (plantilla) – CTI Products TurboVUi Dispatch Client Software User Manual
Page 29
TurboVUi Dispatch
Guía de Instalación y Configuración del Software
29
Sub-Título Overlays (Plantilla)
Cuando se selecciona el sub-título
Overlays
, aparece la siguiente ventana. De clic en
para una nueva
Imagen
Image Overlay
en la
Barra de Herramientas
de la
Ventana GPS
.
Cuando se selecciona una Imagen
Image Overlay
existente, se desplegará un mapa junto con los botones
Browsing for an Image (Buscando una Imagen), Image Transparency (Transparencia de la Imagen), Choosing a
Map Type (Seleccionando un Tipo de Mapa), y Zooming (Acercamiento).
De clic en el botón
para guardar toda configuración de Dispatch .
