Mounting – CTI Products CIB Comparator Interface User Manual
Page 21

CIB Hardware Reference
Mounting
CTI Products, Inc.
68-10854-135
15
6. Mounting
Various mounting kits are available to mount the CIB module.
Mounting Kits
Rack Mount - 4 A size modules
1 Rack Unit (1.75") High
S2-60435
Rack Mount - 2 A size modules plus 1 B size module
1 Rack Unit (1.75") High
(Used to mount 2 CIBs and 1 EXB module.)
S2-60443
Wall Mount - 1 A size module
S2-60444
Digitac Mounting Kit and Cable
Mounts on rear of Digitac comparator.
Includes "T" ribbon cable to connect to P805.
S2-60437
Refer the reference 1, section Mounting Options, for physical details about
mounting the CIB module.
CAUTION
Make sure that any mounting screws used to secure unit to a wall-mount bracket
or Digitac Bracket do not protrude into the unit’s enclosure more than 1/8 inches
from the bottom surface of the unit.
Using a larger screw that touches the PC board inside the unit may damage the
unit when it is powered. Doing so will void the unit’s warranty.
