EN • 9
EN
ChARGING PROGRAMS
Choose program by pressing the MoDE-button.
Adjust parameters according to "ChArgiNg" (6–9).
press STArT/STop button to start the selected program.
The table explains the different Charging Programs:
Program
Battery Size
(Ah)
Explanation Temp range
NoRmAl 20–1500Ah
use for gEl, WET and Mf batteries. -20°C–+50°C
(-4ºf–+122ºf)
AGm 20–1500Ah
use for most AgM batteries. Some AgM should use lower voltage
(NorMAl Mode), check battery manual if unsure.
-20°C–+50°C
(-4ºf–+122ºf)
Ca/Ca 20–1500Ah
use for Ca/Ca batteries. use Ca/Ca program to maximize charge with
minimum loss of fluid. including rECoND step. recond your battery once
per year and after deep discharge to maximise lifetime and capacity.
-20°C–+50°C
(-4ºf–+122ºf)
BooST 20–1500Ah
used for recovery of stratified batteries. -20°C–+50°C
(-4ºf–+122ºf)
Supply 20–1500Ah
use as power supply or use for float maintenance charging when 100%
capacity of the battery is required. Supply program activates step 7 without
time or voltage limitation.
-20°C–+50°C
(-4ºf–+122ºf)
WARNING!
Risk for short circuiting the battery cables. Connect charger cables
to the charger before connecting the battery
WARNING!
Risk for electrical shock if touching positive and negative terminals
when charging
12V/24V
Current Battery size Min Battery size Max
10A 20Ah 300Ah
20A 40Ah 600Ah
30A 60Ah 900Ah
40A 80Ah 1200Ah
50A 100Ah 1500Ah
• Using higher current than recommended may result in batteries not being
completely charged.
•Using lower current than recommended will prolong the charging time.
• The currents are the maximum recommended current for battery charg-
ing. if a parallel consumer is connected then the current setting could be
increased with this current value.
• Some battery manufacturer could recommend different values. Please
check with the manufacturer if uncertain. The main recommendations are
that gel batteries should be charged in the lower current range, power
AgM’s in the upper range and most other battery types in the mid-range.
Model number 1045
Rated Voltage AC 220–240vAC, 47–64hz
Charging voltage Normal 14.4v/28.8v
Max 15.8V/31.6V
Supply 13.6V/27.2V, 14.0V/28.0V
14.4v/28.8, 14.8v/29.6v
Start voltage 2.0v
Output current Max 50A; 70A in supply 12v
Current, mains Max 7.2A
rms
(at full charging current in 24v)
Back current drain* <1Ah/month
Ripple**
<4% of actual DC current
Ambient
temperature
-20°C to +50°C
(-4°f to +122°f)
Charger type 8 step fully automatic charging cycle
Battery types All types of 12v and 24v lead-acid batteries
(WET, Mf, Ca/Ca, AgM and gEl) Check with
your battery supplier for appropriate charge
information
Battery capacity 20Ah–1500Ah
Dimensions 338x178x80mm (L x W x H)
Insulation class ip20
Weight 3.3kg, without cables
Warrenty 2 years
*) Back current drain is the current that drains the battery if the charger is not connected
to the mains. CTEK chargers has a very low back current.
**) The quality of the charging voltage and charging current is very important. A high
current ripple heats up the battery which has an aging effect on the positive electrode.
high voltage ripple could harm other equipment that is connected to the battery. CTEK
battery chargers produce very clean voltage and current with low ripple.
TEChNICAL SPECIFICATION
LIMITED WARRANTY
CTEK SWEDEN AB, issues this limited warranty to the original purchaser of
this product. This limited warranty is not transferable. The warranty applies
to manufacturing faults and material defects for 2 years from the date of
purchase. The customer must return the product together with the receipt
of purchase to the point of purchase. This warranty is void if the battery
charger has been opened, handled carelessly or repaired by anyone
other than CTEK SWEDEN AB or its authorised representatives. The
charger is sealed. removing or damaging the seal will void the warranty.
CTEK SWEDEN AB makes no warranty other than this limited warranty and
is not liable for any other costs other than those mentioned above, i.e. no
consequential damages. Moreover, CTEK SWEDEN AB is not obligated to
any other warranty other than this warranty.
