XNET Network Box Camera User’s Guide
6. Tips for using XNET/XNET-Wireless
6.1. ALARM-IN and ALARM-OUT
ALARM connectors are used to connect various sensing and alerting devices. Examples of
sensing devices are infrared sensors, motion sensors, heat/smoke sensors, magnetic sensor, etc.
ALARM-OUT is used for connecting alerting device such as loud speaker, flashing light, etc.
Figure 6-1. ALARM-IN/ALARM-OUT Connector
6.1.1. ALARM-IN
e
nes providing on-off switching are connected between “+“ and “-” pins. Figure
6-2 shows the input circuit of “Alarm In”.
Connect the two wires of the sensors to “Alarm In”. The sensor type can be set in Administrativ
mode. Output li
