XNET Network Box Camera User’s Guide
Audio Input
Select Line In for
Selection
Select the type of input audio.
using Line-out from audio devices.
Select Mic for using microphone.
Input Video This filed is set by the factory
Video Size
Select a video size for transmission-
z NTSC(30 fps Max.): 720x480, 352x240, 176x144
z PAL/SECAM (25 fps Max.): 720x576, 352x288, 176x144
Interpolation/
De-Interlace
Select the imaging method when the video resolution is Full D1.
z Interpolation: Filtering not used. Provides clear images than
De-Interlace method, but a jaggy image will appear to the
moving object.
z De-Interlace: Using filtering. Proper to the moving objects,
but not clearer than Interpolation method.
Max. upload
rate
Assign maximum bandwidth of the uplink for the network
connected to XNET/XNET-Wireless.
Frame rate
Assign number of video frames to be transmitted for each second.
You can improve picture quality by lowering frame rate for the
same bandwidth.
Video rate Assign bandwidth for transmitting video data.
Audio rate
Assign bandwidth for transmitting audio data. Audio data is not
transmitted if you select “NA”
Check
After you finish set up of video and audio for all the channels, click
on this box to obtain the possible maximum number of users
(Possible Max Users) and remaining network bandwidth
(Remained) remaining when possible maximum users are
connected.
Possible Max
Users
mum simultaneous connections for
the network connection set-up.
It shows the number of maxi
It shows the network bandwidth remaining when Possible Max
Users are connected.
Remained
Video Quality &
Bandwidth
Control
Limited users
Useful network bandwidth varies according to the condition of the
Possible
network. This parameter is used to limit the number of the
simultaneous connections below the number shown in
Max Users .
Save parameters are done. Save the set-up parameters when the set-up
