Page 29
XNET Network Box Camera User’s Guide
5.7. Sensor & Ca
This is the setup pag
sor
user by FTP or E-ma
nfig
pture Setup
e for sen
il upon co
s and video capture conditions. Captured video can be sent to
uration.
Figure 5-9. Sensor & Capture Setup
Sub Field
Field/Button
Description
/Button
Sensor 1
Select sensor type. There are two types of sensors which are
Normal Open and Normal Close.
Sensor Setup
Name
Input logical name for the sensor.
It sets the condition of video transmission via FTP or E-mail.
The XNET/XNET-Wireless supports 2 types of conditions which
are mutually independent.
Sensor
Select
Check to enable Sensor initiated capture.
Video Capture
Condition
Motion
Detection
Select
Check to enable motion detection initiated capture.
Captured
Video
Select a way of sending captured video. You can send
captured video through FTP or E-mail, or both.
