◎ CCD Sensor : 1/4” Interline Transfer CCD
◎ 12x Optical Zoom, 12x Digital Zoom (Max. 144x Zoom)
◎ D
& Ni ht F ti
◎ With RS-485, 422 communication, max. 255 of cameras can be controlled at the same
time.
◎ Using the remote controller can control the camera (max 10 meters range)
Camera Specifications PTZ(Pan/Tilt/Zoom) Control
◎ Day & Night Function
◎ Various Focus Mode : Auto-Focus / Manual Focus / Semi-Auto Focus
◎ Independent & Simultaneous Camera Characteristic Setup in Preset operation ◎ Using the remote controller, can control the camera (max. 10 meters range).
◎ Pelco-D, Pelco-P or SONY protocol can be selected as a control protocol in the current
version of firmware.
※ The function number to be supported for each protocol is different.
(Refer to the section titled “Each protocol function number”, Page 18)
Powerful Pan/Tilt Functions
◎ Max. 360°/sec high speed Pan/Tilt Movement for each preset
◎ Using Vector Drive Technology, Pan/Tilt motions are accomplished in a shortest path.
As a result, time to target view is reduced dramatically and the video on the monitor is
very natural to watch.
◎ For jog operation using a controller, since ultra slow speed 0.05°/sec can be reached, ◎ OSD menu is provided to display the status of camera and to configure the functions
Powerful Pan/Tilt Functions
OSD(On Screen Display) Menu
it is very easy to locate camera to desired target view. Additionally it is easy to move
camera to a desired position with zoom-proportional pan/tilt movement.
◎ Max 127 Presets are assignable and characteristics of each preset can be set up
interactively.
◎ The information such as Camera ID, Pan/Tilt Angle, Alarm Input and Preset can be
displayed on screen.
Preset, Pattern, Swing, Group More..
◎ Max. 127 Presets are assignable and characteristics of each preset can be set up
independently, such as White Balance, Auto Exposure, Label and so on.
◎ Max. 8 set of Swing action can be stored. This enables to move camera repetitively
between two preset positions with designated speed.
◎ Max. 4 of Patterns can be recorded and played back. This enables to move camera to
follow any trajectory operated by joystick as closely as possible.
◎ M 8 t f G ti b t d Thi bl t titi l ◎ Max. 8 set of Group action can be stored. This enables to move camera repetitively
with combination of Preset or Pattern or Swing. A Group is composed of max. 20
entities of Preset/Pattern/Swings.
※ The function number to be supported for each protocol is different.
(Refer to the section titled “Each protocol function number”, Page 18)
