Response from MR88
Byte Name Value Detail
1 Address Byte Address
2 Command 0x81 – 0x88 Get Input Channel n Ack
3 Mono/Stereo 0x00 – 0x01 0x00 = Mono
0x01 = Stereo
4 Input Level 0x00 – 0x02 0x00 = Mic + Phantom
0x01 = Microphone
0x02 = Line
5 Input Gain 0xD8 – 0x14 -40db – +20dB
6 Compression 0x00 – 0x09 0 = Off
9 = Max
7 Eq Low 0xF4 – 0x0C -12dB – +12dB
8 Eq High 0xF4 – 0x0C -12dB – +12dB
9 Output to 0x00 – 0x03 0 = Off
1 = Bus X
2 = Bus Y
3 = Bus X and Bus Y
10 Priority Level 0x01 – 0x04 1 = Priority 1
…..
4 = Priority 4
11 Gate Level 0x00 – 0x22,
0x23 6dB – 40dB and Mute
12 Detector Type 0x00 – 0x04 0x00 = Auto Speech
0x01 = Auto Music
0x02 = Manual
0x03 = Force Off
0x04 = Force On
13 Manual Level 0xD8 – 0x00 -40dB – 0dB
14 Hold Time 0x00 – 0x05 0 = 50mS
1 = 100mS
2 = 200mS
3 = 500mS
4 = 1S
5 = 2S
15 NOMA 0x00 – 0x01 0 = Exclude from Noma
1 = Include in NOMA
