Get Output Channels
Command 0x00
Byte Name Value Detail
1 Address Byte Address
2 Command 0x00 Get Output channels
Response from MR88
Byte Name Value Detail
1 Address Byte Address
2 Command 0x80 Get Output Channels Ack
3 Gain A 0xC4 – 0x00 -60dB to 0dB
4 Gain B 0xC4 – 0x00 -60dB to 0dB
8 Source A 0x00 – 0x03 0x00 = Off
0x01 = Channel X
0x02 = Channel Y
0x03 = Channel X+Y
9 Source B 0x00 – 0x03 0x00 = Off
0x01 = Channel X
0x02 = Channel Y
0x03 = Channel X+Y
Example to get the output settings for mixer address 2 :-
0x7E, 0x02, 0x00, 0x7F, 0xFD, 0x7D
The mixer would respond with, for example :-
0x7E, 0x02, 0x80, 0xFC, 0xF0, 0x01, 0x02, 0x8E, 0x7D
