Byte Name Value Detail
14 VCA 0x00 – 0x04 0x00 = VCA1 to OFF, VCA2 to
OFF
0x01 = VCA1 to ChA, VCA2 to
OFF
0x02 = VCA1 to ChB, VCA2 to
OFF
0x03 = VCA1 to ChA+B, VCA2
to OFF
0x04 = VCA1 to ChA, VCA2 to
ChB
15 Locked 0x00 – 0x01 0x00 = Unlocked
0x01 = Locked
Example to get the system settings from Mixer address 2 :-
0x7E, 0x02, 0x09, 0xF4, 0x7D
The mixer would respond with, for example :-
0x7E, 0x02, 0x89, 0x01, 0x00, 0x00, 0x00, 0x01, 0x02, 0x03, 0x04, 0x05,
0x00, 0x00, 0x00, 0x00, 0x64, 0x7D
