Get System
Command 0x09
Byte
Name
Value
Detail
1
Address
Byte
Address
2
Command
0x09
Get System
Response from MR88
Byte
Name
Value
Detail
1
Address
Byte
Address
2
Command
0x89
Get System Ack
3
Priority 1
0x00 – 0x01
0x00 = Inclusive
0x01 = Exclusive
4
Priority 2
0x00 – 0x01
0x00 = Inclusive
0x01 = Exclusive
5
Priority 3
0x00 – 0x01
0x00 = Inclusive
0x01 = Exclusive
6
Priority 4
0x00 – 0x01
0x00 = Inclusive
0x01 = Exclusive
7
Last Channel On 0x00 – 0x01
0x00 = Disabled
0x01 = Enabled
8
Code 1
0x00 – 0x09
1
st
Code digit 1 - 9
9
Code 2
0x00 – 0x09
2
nd
Code digit 1 - 9
10
Code 3
0x00 – 0x09
3
rd
Code digit 1 - 9
11
Code 4
0x00 – 0x09
4
th
Code digit 1 - 9
12
Control Outputs
0x00 – 0x01
0x00 = High
0x01 = Low
13
Control Inputs
0x00 – 0x01
0x00 = Force off
0x01 = Force on
