Page 25

Get Version

Command 0x7F

Byte

Name

Value

Detail

1

Address

Byte

Address

2

Command

0x7F

Get Version

Response from MR88

Byte

Name

Value

Detail

1

Address

Byte

Address

2

Command

0xFF

Get Version Ack

3

ID1

0x02

4

ID2

0x01

5

Hardware Version

0x00 – 0xFF

Currently 4

6

Hardware State

0x00 – 0xFF

Currently 2

7

Boot Version

0x00 – 0xFF

Currently 1

8

Firmware Major

0x00 – 0xFF

Currently 4

9

Firmware Minor

0x00 – 0xFF

Currently 2

Example to get the version for mixer address 2 :-

0x7E, 0x02, 0x7F, 0xFF, 0x7F, 0xFE, 0x7D

The mixer would respond with, for example :-

0x7E, 0x02, 0xFF, 0x02, 0x01, 0x04, 0x02, 0x01, 0x04, 0x02, 0xEE, 0x7D
