Digital Inputs
7.2 Logical inputs Reg and Init
Principle
The digital inputs Reg and Init are dedicated to the management of the P.I.D. calculation
process.
How does it work
The following table shows the calculation process status for any different combination of Reg
and Init switches positions:
Init Reg PID calculation
0 0 calculation stopped
1 0 calculation initialization
0 1 calculation in process
1 1 calculation in process
0 means: Switch Open / 1 means: switch closed (to the 24Vdc terminal)
35
