Menu OUTPUTS
6.2
DISPLAY output function (AO2)
This function is used to select one of the following four items to be displayed:
-Set point (0 to 10V = whole measurement range as it has already been calibrated)
-Measure (-10V to +10V = whole measurement range as it has already been calibrated)
-Diameter (0 to 10V = 0 to the Max diameter)
-Linear speed for the speed follower menu
