Chapter 10. backup, 1. backup – KT&C K9-s Series User Manual
Page 47
DIGITAL VIDEO RECORDER MANUAL
DIGITAL VIDEO RECODER MANUAL
47
[1] Menu recall : If you select the “AUDIO” during the live or playback, the audio out menu show
up. The menu call is possible by remote controller or mouse.
[2] Mode selection
• OFF : No audio use.
• CH1 : Audio out only from CH1
• CH2 : Audio out only from CH2
• CH3 : Audio out only from CH3
• CH4 : Audio out only from CH4
• Auto : Only selected channel audio out.
• Volume control : If the length of bar increase, the volume louder.
▒ Chapter 10. Backup ▒
10-1. Backup
Selected image can be backup to the external device(USB). Connect the USB pen drive to the DVR
and select ‘BACKUP’ button from remote controller or, click the right button of mouse.
[1] Select the recognized backup device. If it recognized normal, it shows the device capacity
such as ”XXX MB”.
