DIGITAL VIDEO RECORDER MANUAL
DIGITAL VIDEO RECODER MANUAL
38
█ N (Grey) : No record
█ C (Green) : Continuous record
█ M (Blue) : Motion detected record
█ S (Red) : Sensor triggered record
█ M+S (Yellow) : Recording by motion detection or sensor triggering
[How to setup]
• Select a channel
• After selecting the day of the week and time, every mouse click makes color shift like N(Grey)
→ C(Green) → M(Blue) → S(Red) → M+S(Yellow)
• After selecting the other day of the week and time, every OK button click makes color shift.
• Clear : Delect the schedule of the selected channel
• Channel Copy : Copy the currently set recording schedule to the selected channel.
• All Ch to Copy : Copy the currently set recording schedule to all channels.
7-3. Holiday Record
Set holiday record with different option.
[1] 7 different holiday setup can be made.
After selecting record type from H1 to H7, set time with mouse dragging or remote direction
key.
