8. OSD MANUAL
- COMM ADJ : Enable user to set up CAMERA ID, BAUDRATE.
① CAM ID : Enable user to set up Camera ID (0~255).
② BAUDRATE : A communication speed to Communicate with external device.
(2400, 4800, 9600, 19200).
- PRIVACY : Privacy is the function that covers some part on screen
to prevent private life (Maximum 15 point covered).
① ZONE : Enable user to set up positions from 0 to 14.
② MASK : Enable user to set up screen output of chosen position.
③ V START : Mask Vertical start position.
④ V END : Mask Vertical end position.
⑤ H START : Mask Horizontal start position.
⑥ H END : Mask Horizontal end position.
⑦ TOP ANGLE : Top angle position.
⑧ BOTTOM ANGLE : Bottom angle position.
⑨ INITIAL : Enable user to initialize setting of PRIVACY MENU.
CAMM ADJ
>CAM ID ... 000
BAUDRATE ... 9600
RETURN
PRIVACY
>ZONE NO ... 0
MASK ... OFF
V START ... 07
V END ... 12
H START ... 10
H END ... 19
TOP ANGLE ... 00
BOTTOM ANGLE ... 00
INITIAL
RETURN
