26
8. OSD MANUAL
5. DAY&NIGHT
: Conversion of output image COLOR / BW depending on exterior environment
Enable user to set the LEFT, RIGHT KEY in menu.
- D&N MODE
① COLOR : Enable user to fix the output image in color.
② B/W : Enable user to fix the output image in B/W.
③ AUTO : Enable user to convert to COLOR/BW
automatically by luminace element on Screen.
④ EXT : Enable user to convert to COLOR/BW
by signal of the exterior input.
-> Low input signal : COLOR
-> High input signal : BW
- DWELL TIME : In D&N MODE AUTO, enable user to set to delay time for
changing COLOR/BW (0~10sec).
- D->N LEVEL : Day(Color) to Night(BW), level(0~19).
- N->D LEVEL : Night(BW) to Day, level(1~20).
- INITIAL : Enable user to initialize the setting in DAY&NIGHT menu.
DAY & NIGHT
>D&N MODE ... COLOR
DWELL TIME ... ----
D -> N LEVEL ... ----
N -> D LEVEL ... ----
INITIAL
RETURN
