Specifications
General
Product Name
In-LineLinc Relay – INSTEON Remote Control In-Line On/Off
Switch (Dual-Band)
Brand Smarthome
Manufacturer Product Number 2475SDB
UPC 813922011425
FCC ID SBP4773
Patent Number 7,345,998 US, International Patents Pending
Warranty 2 Years, Limited
INSTEON
INSTEON ID 1
INSTEON 256 responder groups & 1 controller group
Maximum Scene Links 417
Scene Commands Supported as
Responder
On Off
Software Configurable Yes, Always
RF Range 150’ Open air
X10 Support Yes
X10 Addresses 1 max, unassigned by default
INSTEON Device Category
0x02
INSTEON Device Subcategory
0x1F
INSTEON Product Key (IPK)
0x000085
Mechanical
Mounting
Mounts inside lighting ballast box in the ceiling or in the wall
Wires
Colors:
White – Neutral 18 gauge
Black – Hot 12 gauge
Red – Load 12 gauge
Copper – Earth Ground 12 gauge
Set Button 1
Beeper Yes
LED White
Dimensions 2.77" H x 1.75" W x 1.47" D
Weight 120 grams / 0.26 pounds
Operating Environment Indoors
Operating Temperature Range 32-104 F
