INSTEON In-LineLinc Relay (Dual-Band) (2475SDB) Manual - Manual (Page 10)

Page 10 of 12 2475SDB - Rev: 1/21/2014 7:58 AM
Operating Humidity Range 0-85% Relative Humidity
Electrical
Voltage
120VAC +/- 10%, Split, Single Phase
240VAC +/- 10%, Single Phase
277VAC +/- 10% Three Phase
Frequency 60Hz
Maximum Load 20 Amps;1800 Watts (for incandescent loads)
Load Type(s) Wired-in incandescent lighting and inductive loads
Retains all settings without power Yes, all saved in Non-volatile EEPROM
Standby power consumption < 1 watt
Safety Approved ETL (Intertek Testing Services)
Certifications FCC, IC Canada
X10 Features (applies to power line only)
X10 Primary Address 1
X10 Status Response Supported
X10 Powerline Frequency 120 KHz
X10 Messages Repeated No
Troubleshooting
Problem Possible Cause Solution
The Status LED on In-
LineLinc is not turning
on and won’t control
the load.
In-LineLinc may not be
getting power.
Make sure the circuit breaker is turned on.
Check the junction box wires to ensure all
connections are tight and no bare wires are
exposed.
In-LineLinc won’t link
or work with a
controller.
The controller might have
been reset without
Unlinking In-LineLinc from
it.
Re-Link In-LineLinc to the controller.
The INSTEON signal may
be too weak.
Add additional INSTEON devices or move around
existing INSTEON devices. All INSTEON devices
act as INSTEON network repeaters.
Large appliances, such as
refrigerators or air
conditioners, may be
producing electrical noise
on the power line.
Install a power line noise filter (#1626-10) to filter
electrical noise and minimize signal attenuation.
