When linking INSTEON devices, the links that
are created are one-way.
The current state of the controlled device is
stored in the link: on, off or dimmed.
Switch A will turn Switch B on and off but
Switch B cannot turn Switch A on or off.
The switch will turn on the Lamp Dimmer to
75% brightness.
A Switch B Lamp Dimmer
NEW
X
NEW
X
®
75%
d
f
h
a
c
e
g
b
INSTEON devices that can turn other devices
on or off are called controllers.
Sensors, Switches, Keypads and the
Hub are common controllers.
NEW
X
®
INSTEON devices that receive the command of a
controller are called responders.
Switches, Keypads, Plug-In Modules and
In-Line Modules are common responders.
NEW
X
®
Responders Controllers
Links Remember a Device’s State Links are One-Way
Understanding Linking
®
®
Neutral
On
Off
Set N
N
Load L1
Line L
