5
Section 1 Specifications
Subject to change without notice
Electrics
Power supply 230 V (Option: 115 V) ±10 % AC voltage, 50/60 Hz
Power consumption
Device with system components: 1500 VA
Line Heater off
Max.
(–20 °C [–4 °F])
start-up
Cont.
(–20 °C [–4 °F])
2 m [6.56 ft]
10 m [32.8 ft]
20 m [65.6 ft]
30 m [98.4 ft] 150 VA
150 VA
150 VA
150 VA 450 VA
950 VA
1500 VA
2100 VA
< 200 VA
< 300 VA
< 400 VA
< 500 VA
Outputs
(Use screened cables!)
Fault contact: potential-free contact (230 V, max. 3 A)
Alarm contact: potential-free contact (230 V, max. 3 A)
Service interface: RS 232
Protection type (control unit) IP55
Fuses
T 4A E; 250V (2 x)
T 7A E; 250V (2 x)
Environment
Medium temperature +5 °C to +40 °C [41 °F to 104 °F]
Ambient temperature –20 °C to +40 °C [–4 °F to 104 °F]
Sample quantity Approx. 600 mL/h for up to 2 process photometers
Delivery height
Module carrier — control unit: 3 m [9.84 ft]
Control unit — process measuring instrument: 7 m [22.97 ft]
General specifications
Line length
Suction tube (heated): 5 m [16.4 ft]
Sample tube (unheated): 2 m [6.56 ft]
Sample tube (heated): 2 m [6.56 ft], 10 m [32.8 ft], 20 m [65.6 ft],
30 m [98.4 ft]
Maintenance requirements Approx. 1 hour/month
Weight
Control unit: approx. 20 kg [44 lb]
Module carrier with 5 m [16.4 ft] suction tube: approx. 3.5 kg [77 lb]
2 m [6.56 ft] sample tube:
approx. 1 kg [2.2 lb]
10 m [32.8 ft] sample tube: approx. 5 kg [11 lb]
20 m [65.6 ft] sample tube: approx. 10 kg [22 lb]
30 m [98.4 ft] sample tube: approx. 15 kg [33 lb]
Dimensions (W × H × D)
Control unit: 430 Ч 530 Ч 220 mm [16.9 Ч 20.86 Ч 8.66 in.]
Filter module: 251 Ч 445 Ч 17 mm [9.9 Ч 17.5 Ч 0.67 in.]
Certification
Certification
CE. The manufacturer clarifies conformity with the applicable EU safety
guidelines and EMC guidelines.
