29
Installation
3.7 Commission the instrument
3.7.1 Filter module
Once installation is complete, the FILTRAX eco can be
commissioned.
1. Make sure that the pump cassette is correctly engaged in the
control unit (refer to Figure 11 Click pump cassette into place
on page 19 ).
2. Unpack the filter module and hook onto the module carrier
using the karabiner (refer to Figure 19 , item 1 ).
3. Connect the sample tube in accordance with Figure 19 .
4. Connect the control unit to the mains and set the instrument
parameters (refer to section 4.3 on page 32 ).
Note: The black 3 mm tube that protrudes from the filter module is not
required when a FILTRAX eco is used.
N O T I C E
Do NOT touch the sensitive filter membrane.
