20
Installation
3.3.3 Install suction tube
Figure 12 Suction tube connection preparation
1 Protective tube (transportation safety device) 4 Cable gland M20 × 1.5
2 Heat-shrink tube 5 Suction tube
3 Metal connection 6 Dummy plug
N O T I C E
Make sure the tubes are connected correctly. The filter module may be
damaged if the sample is sucked back via the sample suction tube.
