Appendix A Modbus register
Table 3 Sensor modBUS registers
Tag Name Group Name Register Data Type Length R/W Description
TURBIDITY FNU Measurement 40001 Float 2 R Turbidity in FNU
TURBIDITY NTU Measurement 40001 Float 2 R Turbidity in NTU
TURBIDITY TEF Measurement 40001 Float 2 R Turbidity in TEF
TURBIDITY FTU Measurement 40001 Float 2 R Turbidity in FTU
TURBIDITY EBC Measurement 40003 Float 2 R Turbidity in EBC
SOLID mg/L Measurement 40005 Float 2 R Solid in mg/L
SOLID ppm Measurement 40005 Float 2 R Solid in ppm
SOLID g/L Measurement 40007 Float 2 R Solid in g/L
SOLID % Measurement 40009 Float 2 R Solid in percent
Reserved Reserved 40011 Unsigned Integer 1 R Reserved
SET PARAMETER Configuration 40012 Unsigned Integer 1 R/W Parameter
UnitTM Unit 40013 Unsigned Integer 1 R/W Turbidity Unit
UnitDS Unit 40014 Unsigned Integer 1 R/W Solid Unit
OFFSET Calibration 40015 Float 2 R/W Turbidity Offset
TRB Factor Calibration 40017 Float 2 R/W Turbidity Factor
TS Factor Calibration 40019 Float 2 R/W Solid Factor
Reserved Reserved 40021 Unsigned Integer 1 R Reserved
RESPONSE TIME Configuration 40022 Unsigned Integer 1 R/W Response time
LOGGER INTERVAL Configuration 40024 Unsigned Integer 1 R/W Log Interval
Outputmodekal Service 40025 Unsigned Integer 1 R/W Calibrate Output Mode
Outputmodesrv Service 40026 Unsigned Integer 1 R/W Output Mode Service
EDITED NAME Configuration 40027 String 8 R/W Measurement Location
SERIAL NUMBER Configuration 40036 String 6 R/W Serial Number
CAL. DATE Configuration 40042 Time2 2 R Default Calibration Date
TURBIDITY Calibration 40044 Float 2 R
Turbidity Sensor Measurement
Value
SOLID Calibration 40046 Float 2 R Solid Sensor Measurement Value
PROGRAM Maintenance 40048 Float 2 R Application Version
BOOTPROGR. Maintenance 40050 Float 2 R Bootloader Version
STRUCTURE Maintenance 40052 Unsigned Integer 1 R Structure Driver Version
FIRMWARE Maintenance 40053 Unsigned Integer 1 R Register Driver Version
CONTENT Maintenance 40054 Unsigned Integer 1 R Firmware Driver Version
FormatMinFNU Configuration 40055 Float 2 R Turbidity Lower Limit in FNU
FormatMaxFNU Configuration 40057 Float 2 R Turbidity Upper Limit in FNU
FormatMinEBC Configuration 40059 Float 2 R Turbidity Lower Limit in EBC
FormatMaxEBC Configuration 40061 Float 2 R Turbidity Upper Limit in EBC
FormatMinGL Configuration 40063 Float 2 R Solid Lower Limit in g/L
FormatMaxGL Configuration 40065 Float 2 R Solid Upper Limit in g/L
FormatMinMGL Configuration 40067 Float 2 R Solid Lower Limit in mg/L
FormatMaxMGL Configuration 40069 Float 2 R Solid Upper Limit in mg/L
